Microwave equipment for drying and sterilizing red dates

Product name:

Microwave equipment for drying and sterilizing red dates

Description:

Tunnel microwave drying and sterilizing machine is widely used in food industry, such as puffing, sterilizing and drying starchy foods, protein foods, rice products, pork skins, fish, and various snacks such as chips, shrimp pieces , apple chips, instant noodles, etc. It is also used as a microwave dryer for sesame seeds, pumpkin seeds, peanuts, Chinese chestnuts, pistachios, cashews, walnuts, almonds, etc.

Online consultation

Product description

Features of microwave equipment for drying and sterilizing red dates

- Customized design according to the characteristics of red dates, beautiful appearance, sophisticated production technology, perfect service, efficient and uniform drying, stable performance, safe and reliable.
- Using food grade stainless steel, the main components of the microwave system are designed and produced by ourselves, and the electrical components are used by well-known global brands.
- Unique microwave field strength design, processed red dates are round and plump, vivid color, no cracking, complete sugar conversion, delicious pulp and long shelf life.
- Equipment ready to use, turned off and stopped, indication of working status, operation of the human-machine interface, programmed PLC control.
- Temperature control system and microwave oven realize communication, which can automatically adjust the intensity of microwave radiation, and realizes high automation of industrial microwave equipment.
- Suitable for all types of highly processed products such as raw dates, dried dates and slices of dates.

Model

Microwave frequency

Voltage/power

Cavity material

Microwave leak

Box temperature

Relative humidity

dimension

XH-100

2450±50MHz

380V/100KW

304 stainless steel

<1mW/c

458C

85%

18000x1500x2200mm

Technical specifications

Model	Frequency(MHz)	Input power(kw)	Output power(kw)	Dimensions(mm)	Drying productivity(kg/h)	Sterilization productivity(kg/h)терилизации
DXY-12	2450	18	12	7200x650x1800	12	100-150
DXY-15	2450	20	15	8300x720x1800	15	120-180
DXY-20	2450	26	20	8500x750x1800	20	180-250
DXY-30	2450	36	30	10500x950x2000	30	280-350
DXY-40	2450	46	40	10500x1050x2000	40	380-450
DXY-50	2450	58	50	12200x1200x2000	50	480-550
DXY-60	2450	68	60	13500x1200x2000	60	500-600
DXY-70	2450	78	70	13500x1550x2000	70	700-800
DXY-80	2450	90	80	15500x1550x2000	80	800-900
DXY-100	2450	110	100	16500x1750x2000	100	1000-1200

Benefits

1. Unlike other puffing methods, this microwave oven is characterized by fast heating and short drying time. It does not induce some unnecessary chemical reactions and solves the problems of high fat content in products made with swelling in oil. The installation preserves the original color, aroma and taste of the products. The entire microwave swelling process is environmentally friendly, without the release of harmful vapors. This microwave equipment uses a physical process for higher thermal efficiency and higher yields than traditional methods.
2. The microwave unit is suitable for low temperature sterilization, ensuring less nutrient loss. The temperature for microwave sterilization is around 80 ℃ and the process itself takes 3 to 5 minutes. This allows you to maximize the preservation of nutrients. Let's take heat treatment of fruits and vegetables as an example. Traditional methods can only retain 46 ~ 50% Vitamin C and 58% Vitamin A. However, during microwave sterilization, 60 ~ 90% Vitamin C and 84% Vitamin A are retained.
3. Ease of operation and management.
4. Cryogenic sterilization preserves nutrients and traditional flavor: Microwave sterilization can be kept at a temperature of 75-80 degrees Celsius for a short time to sterilize the effect, so that it can keep food more nutritious composition and color, aroma, taste, shape and other characteristics, and extended the effect. For example, microwave cooking of vegetables, meat and other nutrients can be increased by 30%.

How is the quality of our products?
Shandong DXY Machinery Equipment Co., Ltd specializes in the production of single screw and twin screw extruders for a variety of food products, microwave drying and sterilization machines. All of our products have passed ISO, CE, RoHS and REACH certification, high quality guarantee, 3 years quality guarantee. We will offer after-sales services for a lifetime.

How is our team?
We have senior management and competent technicians, a research center where experiments, demonstration, teaching and training will be carried out, and at the same time, applied technology experiment is performed according to customers' request. We always pay attention to technical exchange, introduce advanced technologies, offer customers reliable technical support and excellent services.

Delivery time and how to install machinery?
We not only offer systematic automatic production projects, but also offer professional options for individual customer requirements. We have competent technicians and a strict production control system. From the moment of payment of the advance payment, your order is completed in 15 working days.

Where do our products work?
Our products operate and make a profit in countries such as China, Russia, Uzbekistan, South Africa, United Arab Emirates, Pakistan, Iran, Africa and many others. The company offers you the best products and excellent services. Shandong DXY Machinery Equipment Co., Ltd offers you the best products, excellent services. We will be glad to cooperate with you. Let's enjoy joint prosperity!

We will quickly answer your question

We not only offer systematic automatic production projects, but also offer professional options for individual customer requirements. If you have any questions, leave us a message, we will contact you as soon as possible.
We can speak in Russian, Chinese and English.
